顯示器沒有圖像顯示

為了確保圖象主機和顯示器已接通，圖象主機和顯示器的電源開關指示燈是否亮，如不亮，則需進行保險及供電檢查，檢查圖象主機與顯示器的連線、 IN和 OUT接口是否連接。在具有多種視頻信號源選擇器的顯示器中，選擇合適的視頻信號。查看顯示器的相應設置參數，將亮度、顏色、對比度默認設為默認，確保攝像機的連接電纜固定在圖像主機上。在圖象主機和顯示器之間更換視頻電纜，排除可能的電纜損壞。
Display no image display in order to ensure that the image host and the display are connected, whether the power switch indicator light of the image host and the display is on or not, if it is not, a power supply check should be carried out, check the connection between the image host and the Monitor, and the IN and OUT interfaces. In a display with a variety of video signal source selectors, select the appropriate video signal. Check the display settings, set the brightness, color, contrast to the default, to ensure that the camera cable fixed in the image host. Replace the video cable between the image host and the Monitor to eliminate possible cable damage.

監視

錯誤的圖像顏色

錯誤的圖象顏色要求 WB重新校正。先確定 RGB或 YPbPr接口沒有接線錯誤，顯示參數確定，主機參數確認，選擇其它視頻通道進行測試，進行 COLOR BAR測試。檢查設定菜單的字體和顏色是否正常，如果正常，但內視鏡圖像不正常，基本上是內視鏡或攝像頭故障。
Monitor the wrong image color the wrong image color requires WB recalibration. First determine RGB or YPbPr interface no wiring error, display parameters determined, host parameters confirmed, select other video channels for testing, COLOR BAR testing. Check that the font and color of the settings menu are normal, if so, but the endoscopic image is not normal, basically an endoscopic or camera failure.
圖象干擾
