內窺鏡設備維修廠家為您講解軟管內腔鏡的使用方法：正面7個按鍵為主機系統按鍵，與窺頭控制無關。從左到右依次為：The endoscope equipment maintenance manufacturer will explain to you how to use the hose endoscope: the seven keys on the front are the keys of the host system, which has nothing to do with the control of the endoscope head. From left to right:
1.開機鍵：開關機鍵（長按），或確認鍵（短按）。
1. Start key: on / off key (long press), or confirm key (short press).
2.拍錄鍵：拍照、錄像按鍵。
2. Shooting and recording key: shooting and recording keys.
3.退出鍵：菜單鍵或退出鍵。
3. Exit key: menu key or exit key.
4.上鍵：選擇前一個選項或文件。
4. Up key: select the previous option or file.
5.下鍵：選擇下一個選項或文件。
5. Down key: select the next option or file.
6.左鍵：選擇左邊前一個選項。
6. Left button: select the previous option on the left.
7.右鍵：選擇右邊前一個選項。
7. Right click: select the previous option on the right.
一、開關與接口
1、 Switch and interface
1、機身右側： ①、MiniUSB接口
1. Right side of the fuselage: ①. MINIUSB interface
②、視頻接口（AV接口）
② . video interface (AV interface)
③、TF卡插口
③ . TF card socket
④、充電口（通過適配器外接交流電供電）
④ . charging port (external AC power supply through adapter)
⑤、開/關（電源總開關）
⑤ , on / off (main power switch)
2、機身上側： ①、燈光調節（鏡頭燈光亮度調節）
2. Upper side of the fuselage: ①. Light adjustment (lens light brightness adjustment)
二、電池低電量
2、 Low battery
當電池電量不足后，顯示屏幕會有閃爍現象，LED變暗，最后自動關機，此時不要重新開機，請及時從手柄處取出電池，充電，或者連接電源適配器使用。
When the battery is low, the display screen will flicker, the LED will dim, and finally automatically shut down. Do not restart at this time. Please take out the battery from the handle in time, charge it, or connect the power adapter for use.
三、窺頭控制操作（有窺頭操控的機型）
3、 Peep control operation (models with PEEP control)
1、電動360搖桿控制型（H型）
1. Electric 360 rocker control type (H type)
a) 窺頭操縱——可通過推動搖桿，控制窺頭隨動360°轉動。
a) Operation of PEEP head - the peep head can be controlled to rotate 360 ° by pushing the rocker.
b) 窺頭鎖定：垂直按下?lián)u桿頂部，可以實時鎖定窺頭位置，此時，窺頭鎖定指示燈亮（紅色），搖桿操作無動作；再次徑向按下?lián)u桿，窺頭解鎖，窺頭鎖定指示燈滅。
b) Peep head locking: press the top of the rocker vertically to lock the peep head position in real time. At this time, the peep head locking indicator is on (red), and the rocker operation has no action; Press the rocker radially again, the peep head will be unlocked, and the peep head locking indicator light will be off.
2、電動按鍵控制型（K型）
2. Electric key control type (K type)
a)按窺頭操控按鍵的上、下、左、右鍵，即可控制窺頭向上、下、左、右方向轉動。
a) Press the up, down, left and right buttons of the camera head control button to control the camera head to rotate in the up, down, left and right directions.
3、手動撥桿控制型（S型）
3. Manual paddle control type (s type)
通過操作撥桿上下擺動，可控制窺頭的向上、下、左、右方向轉動。
By operating the paddle to swing up and down, the camera head can be controlled to rotate up, down, left and right.
注：窺頭操縱前，應將伸入管打開，切勿盤起操作。
Note: before the operation of the peep head, the extension tube should be opened, and do not turn it up.
四、開/關機
4、 On / off
將手柄底部電池封蓋打開，放入產品配套電池組，電極（帶有金屬圓環端）一端向內，合上電池封蓋；或在充電口，插入電源適配器。
Open the battery cover at the bottom of the handle and put it into the supporting battery pack of the product. One end of the electrode (with metal ring end) faces inward and close the battery cover; Or plug in the power adapter at the charging port.
a) 開機——打開機身右側電源開關，接通整機電源，再長按“開/關機”鍵，屏幕略閃為進入開啟主機狀態。開機后，將直接進入視頻預覽狀態。
a) Power on - turn on the power switch on the right side of the fuselage, turn on the power of the whole machine, and then press the "on / off" key for a long time, and the screen flashes slightly to enter the state of turning on the main machine. After power on, it will directly enter the video preview state.
b) 關機——長按“開/關機”鍵，再關閉電源開關即可。
b) Shutdown - long press the "on / off" key, and then turn off the power switch.
注：關機后，需等待＞15秒后，才能再次開機
Note: after shutdown, wait for > 15 seconds before starting again
五、無線視頻接收器（選配無線視頻接收）
5、 Wireless video receiver (optional wireless video receiver)
1、接收器開/關機
1. Receiver on / off
開機——長按開機鍵（接收屏幕上方左側），屏幕略閃進入開機；
Power on - long press the power on key (on the left side above the receiving screen), and the screen flashes slightly to enter the power on;
關機——長按開機鍵（接收屏幕上方左側），直到屏幕自動關機。
Power off - press and hold the power on button (on the upper left side of the receiving screen) until the screen shuts down automatically.
2、切換頻道（共8個頻道）
2. Switch channels (8 channels in total)
開機后，短按開機鍵（接收屏幕上方左側）可自動切換接收頻道
After power on, short press the power on key (on the left side above the receiving screen) to automatically switch the receiving channel
3、無線視頻觀看
3. Wireless video viewing
a）主機正常開機顯示后，打開主機機身左側無線視頻開關。
a) Turn on the wireless video switch on the left side of the host after the host is normally turned on and displayed.
b）打開無線視頻接收器，短按開機鍵，切換接收頻道，直到正常顯示主機視頻信號。
b) Turn on the wireless video receiver, briefly press the start button to switch the receiving channel until the host video signal is displayed normally.
